MAX12CLM — 12-Inch Active Column Array Speaker
The BareTone MAX12CLM is a two-way active column array speaker designed to provide clear sound projection and wide, even coverage. Combining a 12-inch low-frequency woofer with eight 3-inch column drivers, it is suitable for auditoriums, lecture halls, houses of worship, outdoor performances and commercial events.

Key Features & Technical Specifications

• Speaker type: Two-way active column array speaker, bass-reflex design
• LF component: 12-inch woofer with 2-inch voice coil and ferrite magnet
• Column section: 8 × 3-inch full-range drivers
• Output power: 450 W RMS / 900 W Program / 1,800 W Peak
• Frequency range (-10 dB): 55 Hz–15 kHz
• Maximum SPL: 127 dB
• Nominal coverage: 50° horizontal × 80° vertical
• Crossover: 300 Hz electronic crossover
• I/O connectors: 2 × XLR/¼-inch combination inputs and 1 × XLR output
• Audio processing: Built-in DSP with selectable Music and Voice presets
• Cabinet material: Plastic
• Handle: 1 × top handle
• Pole socket: 35 mm
• Overall dimensions (W × D × H): 375 × 510 × 1,790 mm
• Net weight: 21.5 kg
